ASW610's long-throw 250mm driver allows it to move the large volumes of air needed for high-quality low-frequency output, and its audiophile-standard 200W Class D amplifier keeps the compact unit running cool.
Fill the room with bass, not speakers
ASW610 is compact, making it a subwoofer you can squeeze in anywhere. Or maybe use two for more bass control.
Sealed tight
ASW610's sealed enclosure keeps the bass good and tight (and exciting!).
Technical specfications
Features
- Input level (line in)
- Input level (speaker in)
- Low-pass filter bypass
- Bass extension
- Bass roll-off alignment
- Auto sense on / standby
- Phase switch
Description
Active closed-box subwoofer system
Drive unit
ø250mm (10 in) paper / Aramid fibre cone long-throw
Frequency range
-6dB at 20Hz and 25 / 140Hz adjustable (EQ at A)
Frequency response
±3dB 27Hz – 40 / 140Hz adjustable (EQ at A)
Bass extension
-6dB at 20Hz (position A)
-6dB at 25Hz (position B)
-6dB at 30Hz (position C)
Power output
200W
Rated power consumption
40W / 0.5W standby
Input impedance
33kΩ
Signal / noise
>90dB
Inputs
- Line in (RCA Phono)
- Speaker in (Binding post)
- 12v trigger (3.5mm jack)
- Low-pass filter
- Active 4th-order, variable cut-off frequency
Dimensions
- Height: 310mm (12.2 in) not including feet or spikes
- 322mm (12.7in) including feet
- 338mm (13.3in) including spikes
- Width: 310mm (12.2 in)
- Depth: 347mm (13.66in) not including grilles
- 375mm (14.8 in) including grilles and controls
Net weight
12.5kg (27.6 lb)
Cabinet finishes
- Black
- White
Grille finishes
- Black
- Grey
