For situations when you want near-invisible loudspeakers but refuse to compromise on sound quality.
Technical Specifications
Technical features
Carbon Dome tweeter
Continuum cone FST midrange
Aerofoil profile bass cones
Description
3-way in-ceiling system
Drive units
1x ø25mm (1in) Carbon Dome high-frequency
1x ø100mm (4in) Continuum cone FST midrange
2x ø130mm (5in) Aerofoil profile bass
Frequency range (-6dB)
-6dB at 52Hz and 33kHz
Frequency Response -3dB
55Hz - 28kHz ±3dB
Sensitivity
90dB spl (2.83Vrms, 1m)
Harmonic distortion
2nd and 3rd harmonics (90dB, 1m)
<1% 90Hz - 33kHz
<0.5% 120Hz - 33kHz
Nominal impedance
8Ω (minimum 3.1Ω)
Recommended amplifier power
25W - 200W into 8Ω on unclipped programme
Frame height
355mm (14in)
Frame width
355mm (14in)
Depth
194.5mm (7.66in)
Cut-out height
332mm (13.1in)
Cut-out width
332mm (13.1in)
Cut-out height w/PMK
335mm (13.2in)
Cut-out width w/PMK
335mm (13.2in)
Protrusion
8mm (0.3in)
PMK
7C
Net weight
9kg (19.84lb) Inc accessories
Finishes
Back box: White
Grille: White
