ccm664-hidden-speakers

Custom Install CI 600 Series in ceiling Speaker

B&W 2-way in-ceiling system, 1" soft dome tweeter, 6" Black Glassfibre cone bass/midrange (Pieza)


Código: 31-CCM664

Our Performance Series delivers fantastic sound in an incredibly discreet package. These loudspeakers are engineered by the same team who creates the loudspeakers used in some of the world’s most advanced recording studios.

Technical Specifications
Description

2-way in-ceiling system

Drive Units
1x ø25mm (1in) soft dome tweeter
1x ø150mm (6in) black glassfibre cone bass/midrange

Frequency Range (-6dB)
45Hz – 35kHz

Recommended Amp Power
25 – 130w

Sensitivity SPL (2.83V, 1m)
87dB

Impedance Nominal (min)
8Ω (4.5Ω)

Frame diameter
240mm (9.5in)

Cut-out diameter
202mm (8in)

Depth behind surface
133mm (5.2in)

Protrusion
4mm (0.2in)

Pre-mount Kit
C6

Back Box
6C
