As versatile as it is powerful. You can build your own CT700 home cinema sound system using any combination of models in any position.
3-way vented-box system.
The CT700 flagship combines clarity and power, thanks to a Nautilus™ tube loaded tweeter and dedicated mid and bass drivers. Designed for music or the front channels of a Custom Theater installation, it slots easily into cabinetry.
Technical features
- Nautilus™ tube loaded tweeter
- Aramid Fibre cone FST™ midrange Paper/Aramid
- Fibre cone bass driver
- Flowport™
- Magnetically attached grille
Description
3-way vented-box system
Drive units
1 x ø25mm (1 in) cloth dome high-frequency
1 x ø150mm (6 in) woven Aramid Fibre FST™ mid-range
2 x ø200mm (8 in) Paper/Aramid Fibre bass units
Frequency range
-6dB at 36Hz and 28kHz
Frequency response
42Hz – 22kHz ±3dB on reference axis
Dispersion
Within 2dB of reference response
Horizontal: over 60º arc
Vertical: over 10º arc
Sensitivity
92dB spl (2.83V, 1m)
Harmonic distortion
2nd and 3rd harmonics (90dB, 1m)
<1% 50Hz – 20kHz
Nominal impedance
8Ω (minimum 3.0Ω)
Crossover frequency
350Hz, 4kHz
Recommended amplifier power
50W – 200W into 8Ω on unclipped programme
Max. recommended cable impedance
0.1Ω
Dimensions
- Height: 360mm (14.2 in)
- Width: 606mm (23.9 in)
- Depth: 265mm (10.5 in)
- Depth with grille: 288mm (11.3 in)
Net Weight
21.5kg ( 47.9lb)
Finishes
Cabinet Black painted
Grille Black cloth
