SSF-TRIHOLEP Tri-Hole Stripping Tool
This stripping tool is not intended for use when installing mechanical splices, such as Cleerline SSF™ connectors, on SSF™ fiber. SSF™ polymer coating must remain in place for non-fusion splicing applications.
The Cleerline SSF™ Tri-Hole Fiber Optic Stripping Tool allows the easy removal of SSF™ patented polymer coating. Use these strippers to prepare SSF™ fiber for fusion splicing.
Successful fusion splicing of SSF™ fibers requires complete removal of the protective SSF™ polymer coating at the glass level.
The SSF-TRIHOLEP has three openings, allowing preparation of SSF™ or traditional fibers with up to a 3.0 mm jacket.
Each stripping tool package includes a bristled cleaning brush for maintenance of the tool’s openings.
Features
- Allows complete removal of SSF™ polymer coating for fusion splicing
- Compatible with traditional and SSF™ fibers with up to a 3.0 mm outer diameter
- Includes cleaning brush for maintenance.
- Preparing Traditional (non-SSF™) fibers for termination/splicing
Specifications
| Specifications | |
|---|---|
| Compatible Cables | SSF™ and Traditional Fiber Optic Cables |
| Max Jacketed Cable Diameter | 3.0 mm |
| Length | 6” / 152 mm |
| Openings | |
|---|---|
| 1.6-3.0 mm --- 600-900 μm | SSF™ & Traditional Fiber Jacket Removal |
| 250-900 μm --- 125 μm | Traditional Fiber Prep & SSF™ Fusion Splicing |
| 125 μm --- SSF™ | Removal of SSF™ Polymer For Fusion Splicing ONLY |
