Overall
Colors Midnight Black
Transducers 15” Long-Throw woofer
Passive Radiators Dual 15” XBR™ Configuration
Bass Type Bass Radiator
Feet Permanently Installed Feet with Rubber Pad (no leveling)
Dimensions 24.14" x 23.44" x 24.91"
612.6 x 594.4 x 632.7mm
Performance
Amplifier Type Class H Digital
Peak Power 1500W
Continuous (RMS) 500W
Frequency Response (-/+ 3dB) 20 Hz → 150 Hz
Low-Pass Crossover Freq 40 Hz → 120 Hz
Phase Adjustment 0 to 180 degrees
(by 45 degree increments)
Power Supply Internal
IEC 3 prong Jack
120V/240V switch
Europe (<.5W Compliance) Yes
Inputs
LFE Single RCA
Speaker Left/Right 5-Way binding posts
Controls
Main Power On/Off
Volume Control +/-/ Mute Buttons
Low Pass Control +/- Buttons
Phase Control Toggle Button
Status RGB LED Yes
|
