Overall
Colors Glacier White & Midnight Black
Transducers 8” long-throw woofer
Passive Radiators Dual 8” 3XR™ Configuration
Bass Type Bass Radiator
Feet Permanently Installed Feet with Rubber Pad
Dimensions 12.8” x 12.0” x 13.1”
324.8 x 305.8 x 331.6 mm
Performance
Amplifier Type Class D
Peak Power 500W
Continuous (RMS) 200W
Frequency Response (-/+ 3dB) 35 Hz → 200 Hz
Low-Pass Crossover Freq 60 Hz → 120 Hz
Phase Adjustment 0 / 180°
Power Supply Internal
IEC 3 prong jack
120V/240V switch
Europe (<.5W Compliance) Yes
Inputs
LFE Single RCA
Speaker Left/Right 5-way binding posts
Controls
Main Power Auto/Off
Volume Control Potentiometer w/ center detent
Low Pass Control Potentiometer w/ center detent
Phase Control 2-way switch
Status RGB LED Yes
