Overall
Total Pieces 1
Included Accessories
• (2) ¼” 20 Thread Cover Plug
• (1) Tripod Base
• (1) Molded Keyhole Hanger
Cabinet Warranty 5 years
Drivers Warranty 5 years
Original Purchaser Only Yes
Carton 1 12.25" (31.12 cm) h x 8.63" (21.92 cm) w x 8.56" (21.74 cm) d - 8 lbs (3.63 kg)
Satellite Speakers
Total Pieces 1
Availability US
Orientation
• Vertical
• Horizontal
Driver Complement
• (1) 1" (2.54 cm) d (Round) - Tweeter
• (1) 5.25" (13.34 cm) d (Round) - Mid/Woofer
• (1) 5.25" (13.34 cm) d (Round) - Bass Radiator
Height 10.88" (27.64 cm)
Width 6.25" (15.88 cm)
Depth 6.5" (16.51 cm)
Weight 7.25 lbs (3.29 kg)
Audio Inputs
Speaker Inputs (1) Pair of 5-Way Binding Posts - Gold-Plated
Total Frequency Response 47 Hz → 30,000 Hz
Nominal Impedance 8
Max Sensitivity (1 watt @ 1 meter) 91 dB
A/V Receiver Crossover Settings Small (80 Hz)
Mounting Type 1/4 in - 20 Threaded Insert & Keyhole Hanger
Mounting Location
• Bottom of speaker
• Back of speaker
