Overall
Total Pieces 1
Included Accessories • (1) Wall Bracket with Thumb Screws
Cabinet Warranty 5 years
Drivers Warranty 5 years
Carton 1 17.5" (44.45 cm) h x 11.5" (29.21 cm) w x 11.5" (29.21 cm) d - 10.42 lbs (4.73 kg)
ALL-WEATHER SPEAKER
Qty Included 1
Orientation • Horizontal
• Vertical
Height 8.88" (22.56 cm)
Width 14.44" (36.68 cm)
Depth 9.25" (23.5 cm)
Weight 9.2 lbs (4.17 kg)
Driver Enclosure Type PolyStone
Driver Complement • (1) 1" (2.54 cm) d (Round) Pure Aluminum Dome - Tweeter
• (1) 6.5" (16.51 cm) d (Round) BDSS Bass - Mid/Woofer
• (1) 5.5" (13.97 cm) h x 10" (25.4 cm) w (Oval) Pressure Driven - Bass Radiator
Total Frequency Response 40 Hz → 30,000 Hz
Nominal Impedance 8 ohms
Sensitivity (1 watt @ 1 meter) 92 dB
Type A/V Receiver Crossover Setting
Peak Power Handling 200 watts
A/V Receiver Crossover Settings Large (40 Hz)
Audio Inputs
Speaker Inputs (1) Pair of 5-Way Binding Posts - Gold Plated
