Overall
Total Pieces 1
Included Accessories • (1) Rack Mount Kit
Required Accessories • (2) IW Sub 10/10 or IW Sub Reference
Electronics Warranty 3 years
Carton 1 6.75" (17.15 cm) h x 22" (55.88 cm) w x 11" (27.94 cm) d - 28 lbs (12.7 kg)
REFERENCE IN-WALL SUBWOOFER AMPLIFIER
Qty Included 1
Height 3.44" (8.74 cm)
Width 17.06" (43.33 cm)
Depth 9.625" (24.45 cm)
Weight 25 lbs (11.34 kg)
Filter 40 Hz → 150 Hz, Slope of 12 dB per Octave
Phase Settings (Continuous) 0° → 180°
Remote Power Input 12 volt Trigger [.125" Mini Plug (.32cm)]
Fuse Type 6.3 amp 250 volt {"label":"Slo Blo","value":"Slo Blo","selected":true}
US Voltage 110 volts A/C
International Voltage 220 volts A/C
