AVR-X1800H
Enjoy incredible 8K video and 3D audio from the AVR-X1800H. It easily fills small to medium-size rooms with brilliant audio from a 7.2 or 5.2.2 setup with Dolby Atmos and DTS:X. And with HEOS® Built-in, you can wirelessly stream music and share with every HEOS-enabled speaker around your home.
Highlights:
- High performance discrete seven-channel amplifier: Discrete high-current amplifiers on all channels deliver up to 80W per channel (at 8 ohms, 20–20 kHz, THD 0.08%)—enough power to drive most speakers in a mid-size room.
- Immersive audio experience: Get immersed in music and movies with Dolby Atmos® and DTS:X® plus Dolby Surround and DTS Neural:X upmixer to optimize legacy content.
- Advanced 8K home theater 8K video is supported on three of six HDMI inputs and one output. Enjoy easy video compatibility and great picture quality with HLG, HDR, Dolby Vision, HDR10+, and Dynamic HDR pass-through.
- HEOS® Built-in technology Stream music wirelessly to compatible HEOS-enabled components from a variety of streaming services. Add Denon® Home speakers to other rooms and control it all with the HEOS app.
- Built-in Wi-Fi and Bluetooth: Provides both Wi-Fi and Bluetooth connectivity for your wireless network or direct music streaming from your smart devices. Use AirPlay to stream Apple Music.
- Simple setup and Audyssey room-correction technology: The award-winning guided setup assistant provides clear, step-by-step instructions to get you started. Included Audyssey EQ software accurately calibrates sound to optimize the listening experience in your room.
- Over a century of innovation: Founded in 1910, Denon enables the moments that matter through the relentless pursuit of quality, innovation, and audio performance.
Specifications:
- Number of Power Amps: 7
- Power Output: 80 watts per channel (8 ohm, 20 Hz–20 Khz, 0.08% 2ch drive) 120 watts per channel (6 ohm, 1 kHz, 0.7% 2ch drive) 175 watts per channel (6 ohm, 1 kHz, 10% 1ch drive)
- System Remote Control: RC-1257
- Power Consumption: 430 W
- Power Consumption (No Sound, ECO on/off): 29W/39W
- Standby Consumption in W: 0.1
- CEC Standby Consumption in W: 0.5
- Maximum Dimensions (W × D × H) Antenna: Horizontal (in) Antenna: Vertical (in): 17.1 × 13.3 × 6.0 17.1 × 13.3 × 8.5
- Weight (lbs): 19.0
- HDMI In/Out:6/1
- Multi-Room Video Out: Video, HDMI: None
- Analog In/Out 2/-
- Phono (MM) In Yes
- Digital in: Optical/Coaxial 2/1
- Multi-Room Out: Analog/Digital 1/-
- Multichannel Pre-Out Yes (2.2)
- Subwoofer Out: 2
- Number of speaker terminals: 7
|
