JBL Invisible Loudspeaker Synthesis

Conceal C83

The JBL Conceal C83 Invisible Loudspeaker is a high-performance 3-element design built around a patented compression molded baffle and paintable Fidelity Glass™ outer skin. The finished loudspeaker panel installs easily and disappears completely into the surrounding walls or ceiling, allowing optimal placement virtually anywhere in a home. The JBL Conceal Series is the ultimate solution for high-performance architectural audio.

Type

3-way In-Wall/In-Ceiling loudspeaker

Low Frequency Driver

8-inch (203mm) woofer with 1.5-inch (38mm) voice coil

Mid Frequency Driver

1.18-inch (30mm) voice coil transducer with neodymium magnet

High Frequency Driver

1-inch (25mm) voice coil transducer with neodymium magnet

Recommended Amplifier Power

50 - 160 WRMS

Impedance

4 Ohm

Loudspeaker Sensitivity

84 dB/1W/1m measured in-room

Frequency Response

45 Hz - 20 kHz (-6 dB) measured in-room

Crossover Frequency

500 Hz

Enclosure Type

Sealed, with wooden back-box

Protection

Two independent self-resetting devices (LF and MF/HF)

Input Type

Five-way gold-plated spring-loaded binding posts

Warranty

5 Years

Panel Dimensions

22" H x 15-7/8" W x 3-7/8" D (559mm H x 403mm W x 98mm D)

Cut-out Dimensions

22-1/8” H x 16” W (562mm H x 406mm W)

Mounting Depth

3-3/8-inches (86mm)

Product Weight

21.8 lbs (9.9kg)

Shipping Weight

25.5 lbs (11.5kg)
