FEATURES
• Plug & Play
• Wireless Connectivity
• Works With Any Googlecast Speaker
• Ethernet Hardwired Connection
• APP based DSP
• High Quality Audio
• App control via IOS or Android, full control with easy drag and drop zoning
SPEAKER
• Sound Quality THD+N<0.009%, 40Hz-200Hz @ -10dB
• RMS Power: 50W RMS @ 4 Ohm load
• Sensitivity (1W/1m): 90dB
• Type: Class D (Digital)
• Audio Compression: 192Khz/24bits
• Woofer: 4” Polypropylene Driver / 2 x 4” Passive radiator
MUSIC ACCESS
• Audio Formats Supported: MP3, WMA, AAC (MPEG4), AAC+, ALAC, FLAC, APE, WAV, OGG, LPCM
• Audio Sample Rate: up to 192kHz 24bit
• Music Services Supported by Lithe Audio include; Airable Radio, Podcast, Tidal, Deezer, Soundmachine, Amazon Music, Napster, Spotify, etc.
• Operating Systems (for stored files) Windows XP SP3 and higher; Mac OS X 10.6.8 and higher; NAS (networkattached storage) devices supporting CIFS
GENERAL
• 50/60Hz / 3A
• Output Supply : DC24V / 3A >5mins
• DC24V / 5A Peak power >10s
• Dimensions (W x D) 174 x 174 mm (6.85 x 6.85 in)
• Weight 3kg (6.61 lbs) • Operating Temperature 0º to 40º C (32º to 104º F)
• Storage Temperature -20º to 70º C (4º to 158º F)
• Standby power: 1.3W / 0.02A
• Connected power: 1.5W / 0.03A
• Playing Music: 2.8W - 10.5W / 0.03A - 0.09A
WIRELESS NETWORKING
• Expandable up to 30 speakers within same Wi-Fi network
• Wi-Fi Connectivity: Wi-Fi CERTIFIED™ 802.11 b, g, n, ac WPA™ - Personal WPA2™ - Personal WMM®, Wi-Fi Protected Setup™
• Wireless connectivity works on your home Wi-Fi network with both 2.4GHz/5GHz broadcast routers
• Internet connection required for access to Internet radio stations, online music services and software updates.
WHAT'S IN THE BOX
• WiFi Ceiling Speaker
• Power Supply
• Cutting template
• Instruction manual
