STEREO 70s
SLIMLINE STEREO RECEIVER WITH 75W, 8K AND 6 HDMI INPUTS
Get serious home cinema with only two speakers. All the technology found in full-size surround sound AV receivers in a slimline, stereo receiver. 75-watts-per-channel, with 8K HDMI, subwoofer output, and streaming built-in.
Technical Specifications
Power Amplifier
Number of Powered Channels 2
Power Output (8 ohm, 20 Hz - 20 kHz, 0.08% 2ch Drive) 75 W
Power Output (6 ohm, 1 kHz, 0.7% 2ch Drive) 100 W
Power Output (6 ohm, 1 kHz, 10% 1ch Drive) 150 W
Discrete Power Amplifier Yes
Amplifier Topology Class A/B
Inputs/Outputs
HDMI In / Out 6 / 1
Analog In / Fixed Level Out 3 in / out
Phono (MM) In Yes
Digital In: Optical / Coaxial 1 / 1
Multi-Room Out: analog / digital 1 / 0
Multichannel Preamp Out 2.2
Subwoofer Out 2
Number of Speaker Terminals 4
Speaker A / B Yes
USB Audio USB A (Host)
AM/FM Tuner Yes
Multichannel Surround Technologies
Max Number of Processing (Preamp) Channels 2,1
HDMI
Total HDMI Inputs / No. Support 8K 6 / 3
HDCP2.3 support Yes
HDMI Outputs: Main / Zone 1 / 0
HDMI Upscaling 1080P/4K to 8K
Audio Return Channel ARC
Video Dynamic Range HDR / HLG / Dolby Vision / HDR10+ / Dynamic HDR
ALLM (Auto Low Latency Mode) Pass-through for gaming Yes
Variable Refresh Rate / Quick Frame Transport Yes / Yes
HDMI Pass-Through in Standby Mode Yes
Performance Technologies
Pure Direct Mode Yes
Gold Plated RCA Terminals Yes
Hyper Dynamic Amplifier Modules (HDAM) Yes
Music File Support
Lossy Formats MP3 / WMA / AAC
Lossless formats FLAC HD 192/24 / WAV 192/24 / ALAC 192/24
DSD Audio 2.8 MHz / 5.6MHz
Gapless Playback FLAC, WAV ,ALAC ,DSD
Compressed Audio Enhancer: MDAX2 Yes
Network Audio Sharing Yes
Streaming Services
HEOS Multi-room and Streaming Yes
AirPlay Audio Streaming AirPlay2
Internet Radio TuneIn
Spotify* Spotify Connect
*availability of services might vary per region
Other Streaming Services * Amazon Music HD/Amazon Music / TIDAL / Deezer / iHeart Radio / Napster / Soundcloud / Mood Mix
*availability of services might vary per region
Roon tested Yes
Pandora Yes
SiriusXM Yes
Network Connectivity
Ethernet Ports Yes
Bluetooth Re-transmit for Bluetooth headphones Yes (with volume control)
Wi-Fi Yes
Bluetooth Yes
Smart Home Integration And Control
Voice Assistant Compatibility Alexa / Google Voice Assistant / Apple HomePod / JoshAi
App for Smart Phones & Tablets (iOS & Android) Marantz AVR App
HEOS Multi-Room Integrated Yes
HEOS Link Compatibility: IR/ IP Yes / Yes
Multi-Room zones 1
Zone Audio Source: HDMI / Opt, Coax / Network, USB / Analog 2 Ch / 2Ch / Yes / Yes
Zone Audio Output: Speaker / Preout No/Yes
HDMI Diagnostics Yes
Others
Front Display port hole OLED
GUI Languages English, Spanish, French
Setup Assistant Yes
Smart Select on Remote Yes
Firmware Update by Network / USB Yes / Yes
ECO Mode Yes
Auto Power off Yes
Sleep Timer Yes
General
System Remote Control RC-052SR
Power Consumption in W 210
Standby Consumption in W 0.2
CEC Standby Consumption in W 0.5
Network Standby Consumption in W Less than 2.0
Maximum Dimensions 【 w/o Antenna :(W x D x H) in inches 】:
【 17.4 x 14.7 x 4.3 】
What's in the box Main unit, remote control, batteries, AM/FM antennas, wire labels, quick start guide, Audyssey microphone, card board microphone stand, 2 External Detachable Antenna, AC cord
UPC code 747192140267
