Switch de Red Netgear

Netgear GS752TPP-300NAS

nhance your small-to-medium business's network to support power over Ethernet (PoE) devices such as IP security cameras, access points, and VoIP phones with the GS752TPPv3 48-Port Gigabit PoE-Compliant Managed Network Switch from Netgear. This managed rackmount switch features 48 PoE-compatible Gigabit Ethernet RJ45 ports, each of which can each supply 30W of power with a 760W budget to compatible devices. Integrated Layer 2 and Layer 2+ / Layer 3 Lite features, such as static routing, dynamic VLAN assignment, and automatic voice and video prioritization, help enhance overall performance and PoE functionality.

Powered by an 800 MHz ARM A55 single-core processor with 512MB RAM, the GS752TPPv3 is designed to provide smooth data transfers with a 104 Gb/s switching capacity and 77.38 Mpps forwarding rate. Four dedicated Gigabit SFP ports are available for high-speed fiber uplink connections. One year of Netgear Insight access is included, which allows for cloud-based management via mobile app or web browser. This switch is backed by a Netgear ProSAFE limited lifetime warranty, limited lifetime next-business-day hardware replacement, and limited lifetime 24/7 advanced technical support via online chat.

Netgear Insight
Netgear Insight Cloud management enables features that allow businesses to configure and deploy settings from anywhere using the Netgear Insight app from mobile devices or the Insight Cloud portal from any web browser. A 1-year subscription is included.
Dynamic VLAN Assignment
IP phones and PCs can authenticate on the same port but under different VLAN assignment policies. Users are free to move around and enjoy the same level of network access regardless of their physical location in the network.
Static Routing
A simple way to provide segmentation of the network with internal routing through the switch, reserving the router for external traffic routing only, making the entire network more efficient.
Robust Security
Secure your network against external attacks with features such as 802.1x authentication, DHCP filtering, port-based security by locked MAC, and ACL filtering based on MAC and IP addresses.
Auto VoIP Prioritization
Automatic Voice over IP (VoIP) prioritization simplifies most complex multi-vendor IP telephones deployments either based on protocols (SIP, H323, and SCCP) or on OUI bytes (default database and user based OUIs) in the phone source MAC address.

Key Specs

Inputs/Outputs
48x RJ45 Gigabit Ethernet PoE+ (30 W, 802.3at)
4x SFP Gigabit Ethernet WAN
1x USB-A
Stackable
No
Switching Bandwidth
104 Gb/s (Non-Blocking)
PoE Power Budget
760 W.

Performance

Latency
2.5 to 3.3 µs
Forwarding Rate
77.38 Mpps
Switching Bandwidth
104 Gb/s (Non-Blocking)
Priority Queues
8
Packet Buffer
1.5 MB

Computer

Flash Memory
64 MB
CPU
Single-Core: Up to 800 MHz A ( )
Memory
512 MB

Electrical

PoE Power Budget
760 W
Power Draw
29.00 W (Idle)
861.00 W (Max)
Input Power
100 to 240 VAC, 50 / 60 Hz
Power Supply Type
Internal

Environmental

Operating Temperature
32 to 82°F / 0 to 50°C
Operating Humidity
95%
Storage Temperature
-4 to 158°F / -20 to 70°C
Storage Humidity
95% (Non-Condensing)
Noise Level
39.3 dB.
